EVCO S.p.A. Vcolor 818 | Installer manual ver. 1.1 | Code 144VC818E114
page 72 of 94
i5 0 1 - - - - 1
effect caused by the activation of the high pressure input
0 = no effect
1 = the compressor and the evaporator fan will be off
and the condenser fan will be on. On expiry of the
time established with parameter i7, the 3 digit
display will show the flashing “HP” code and the
buzzer will be activated (until the input is
deactivated)
i6 0 1 - - - - 0
type of high pressure input
0 = normally open (input active with closed contact)
1 = normally closed (input active with open contact)
i7 -1 240 s 5
high pressure alarm signalling delay (“HP” code)
-1 = the alarm will not be signalled
i8 0 1 - - - - 0
type of low pressure input
0 = normally open (input active with closed contact)
1 = normally closed (input active with open contact)
i9 -1 240 s 5
low pressure alarm signalling delay (“LP” code)
-1 = the alarm will not be signalled
i10 0 1 - - - - 0
type of compressor circuit breaker protection input contact
0 = normally open (input active with closed contact)
1 = normally closed (input active with open contact)
i11 -1 240 s 5
compressor circuit breaker protection alarm signalling delay
(“CtH” code)
-1 = the alarm will not be signalled
i12 - - - - - - - - - - - - - - - - reserved
Par. Min. Max. Unit Default Digital outputs
u1 0 1 - - - - 0
utility managed by the output K8 (15)
0 = pump down valve (in this case, parameter u12 will
have meaning)
1 = alarm output
u5 -99 99 °C/°F (1) 2
cabinet temperature over which the door heating elements
are off (4)
