2description, 1 description of the user interface – EVCO EVCSR818P9EF User Manual
Page 8
EVCO S.p.A.
Vcolor 818
| Installer manual ver. 1.1 | Code 144VC818E114
page 8 of 94
2
DESCRIPTION
2.1
Description of the user interface
The following drawing illustrates the aspect of the Vcolor 818 user interface.
The following table illustrates the meaning of Vcolor 818 user interface parts.
Part
Meaning
1
Interactive keys and display
2
USB serial port
For further information, see the next chapters.
