TOSHIBA
6 F 8 A 0 7 7 0
T o
change the 4-2()mA Alarm output functions:
1 he following ex;imple shows how to change the 4-20mA AUirm output function from No, 1
to No. 3.
Key operation
Display example
Description
SET
□
D3: 4-20 ALM. OUT
1 OntA
Press [SET] first to sturt the items selection sequence
and .select 1)34-20 ALM*OLTfrom nmong the
configuration items using [ ► ] and [
a
) keys. Then
press [SET] again
to
display the
current
hum out
luiLCtion
fl: 4.0mA in this example).
►
□
D3: 4-20 ALM. OUT
1:4. OmA
Pressing 1 ► j, the cursor appears.
A
D3: 4-20 ALM. OUT
3:24. GriA
Grange the value to “3” by pressing [
a
] twice.
SEl
□
D3: 4-20 ALM. OUT
3:24. GnA
Pressing [SET],
the
cursor disappears and the new
burn out function display Dickers, Press [SET] again
to
save the new function.
SFT
□
D3: 4-20 ALM. OUT
Pressing [SET], the system returns to the items
selection sequence.
-
