TOSHIBA
6 F 8 A 0 7 7 0
To change the digital I/O functions:
The following example shows how Lo chiinge the DOl function from No- I to No, 3,
Key operation
Display example
Description
SET
□
FI: DOl FUNCT.
1:H ALM
Press
[SET]
first to
start the items
selection sequence
,ind select FI:
DOl
FUNCT. from among the
:onfiguration items using [
► j
and [
a
j
keys- Ehen
press [SET] again to display the current DOl function
[1: H ALM in this example).
►
FI: DOl FUNCT
1:H ALM
[dressing [ ► ]♦ the cursor appears.
▲
□
FI: DOl FUNCT
3:EMPTY ALM
Change the value lo by pressing [
a
] twice.
SET
□
FI: DOl FUNCT
3:EMPTY ALM
Pressing [SET]
t
the cursor disappears and the new DOl
function display flickers. Press fSET] again to save the
new function-
SET
□
FI: DOl FUNCT
Pressing [SET], the system returns to the items
selection sequence,
-
72
-
