TOSHIBA
6 F 8 A 0 7 7 0
Using the optional DI signal
Remote operations Гог the totalizer and pulse output can be conducted using the optional DT
signal. The rollowijtg functions in the table can be performed. See 8.2.9 “Digital VO” to
select these lunciions.
Dl .signal(normal converter, detective level: H level)
Digital input (Dl)
Functions
1Л voltage level Totalizer and pulse output
Totalizer
Llevel
Stops the totalizer and the pulse output.
Siarl/Siop H level
Starts the totalizer and the pulse output.
Totalizer
И level
Stops and clears (resets) the totalizer.
Reset/Start Í. level
Starts the totalizer and the puhe output.
* In case of the converter for special specifications (refer to 7.3.3 “Converter for Spcciai
specifications"), you can select Digital Input Detective Level (Only for Counter Control).
For detail, see 8.2,19 “Digital Inpu: Detective LevcF'
“Select H level(l:H LEVFd.) ; refer lo upper table,“ Dl signal(normal converter,
deteclive kvd; H level)”.
“Select L level(0:L LFVEL) : refer to under table,“ Dl signal(converter for
special specifications detective level: L level)“,
1)1 signalfconvcrter for special specifications, detective level: L level)
Digital input (Dl)
Functions
Dl voltage level Totalizer and pulse output
Totalizer
L level Starts ihe totalizer and the puke output.
Start/Slop J1 level
Stops the totalizer and the pulse output.
Totalizer
11 level
Starts the totalizer and the pulse output.
Reset/Starl i.kvel
Stops and clears (resets) the totalizer.
- 114 -
