TOSHIBA
6 F 8 A 0 7 7 0
Proceed as follows to check or chfingc each cansLaitl,
I To check each constant:
Key operation
Display exarnple
Description
SET
□
C2: RANGE 1
02. 000
Ш / &
Press [SET] first to start the ilcms selection
sequence and select C2: RAN(iE 1 from among the
configuration items using [ ► ] and [ ^ ] keys.
Then press [SET] again to display the current
span for Range 1.
SET
□
C2: RANGE t
Pressing [SET], the system returns to the items
selection sci|uence,
Range type. Span. Hysteresis can be selected by the configuration items as follows:
Range type Cl: RANGE ТУРЕ
Span of Range 1 C2 : RANGE 1
Span of Range 2 C3 : RANGE
2
Span of Range 3 Cd: RANGE 3
Span of Range 4 CS: RANGE d
Hvsieresis
C6: RANGE HVST
- 61 -
