TOSHIBA
6 F 8 A 0 7 7 0
The i'oJlowing exiimpJe shows; how lo chiinge the 3:ero offset value from +1.0% lo - 2 . 5 % .
Key operation Display example Description
SET
□
Ml: MANUAL ZERO
tool. 0\
Press [SET] first to start the items selection sequence
and select Ml: MANUAL ZERO from among iJie
configuration items using [ ► ] and [ a ] keys. Then
press [SHl ] again to display lire current zero offset
value.
►
□ Ml: MANUAL ZERO
fOOl. Q \
Pressing [ ► the cursor appears.
(If necessary, press [ ► ] as many times as
necessary to move the cursor to ihe desired digit to
chanee*)
▲
Ml: MANUAL ZERO
-001. OK
-002. OK
-002. 5K
Change the si^ code (“+*^ lo by pressing [ a J.
Then move the cursor to another digit by pressing [ ► ]
and change the value. In this example repeat this process
until the display shows “-(102,5 (Note)
SET
□
Ml: MANUAL ZERO
-002. SK
Pressing [SE'rji the cursor disappears and the changed
value display flickers. Press [SETj again to .save the
value.
SET
□ Ml: MANUAL ZERO Pressing [SET], the system returns Lo the setting
items selection sequence.
Note: If you try to set the value above +0.125 m/s or below -0.125 m/s, the error messages
♦ K OVER SPEC or* L. OVER SPEC, respectively, appears.
Set the value within i0.125
-
