S A Wiring Procedure
Cable terminaLion Eind cabJe connections are described below.
5,4.1 Cable Termination
âs
CAUTION
■ Do not conduct w'iriitg work w hen
■ Do not work on piping and w^nring
power is applied.
with wet hands.
Wiring while power is ap-
0
DON’T
Wet hands may result in
( plied can cause eledric
shuck.
DON^T
electric shock.
IMPORTANT
The apparatus should not be provided wilh the cable glands,
Please prepare yourself for the cable glands which could be used in Division2 hazardous
locations.
Use cables as specified in Table 5,1. First. Remove the cable sheath about 70 mm from the
end to expose the coated wires and then strip the wires about 10 mm. Then attach an
M4’size compression terminal lug to the end of each wire using a compression looL The
compression terminal should be of Ihe kind with insulated sleeve to prevent shorts betw^een
adjacent terminals. The overall length of the wire with the terminal attached should be about
60 mm. See Figure 5.4 bdow'.
M4-sizc compression terminal lug
-
30
-
