BUCHI PrepChrom C-700 - Manual (Page 93)

BÜCHI Labortechnik AG Maintenance | 7
PrepChrom C­700 93/110
u 7.3.1 UV Detector cover, removal [ } page 90].
Tasks
u Loosen the TORX screw (1).
• TORX screw driver T20
u Turn the lamp socket (2) to get access to the lamp mounting base.
u Disconnect the electric plug (2).
u Remove the 2 TORX screws (3).
• TORX screw driver T10
u Remove the lamp (1).
7.3.4.2 Detector lamp, installation
NOTICE
Risk of deuterium lamp damage.
Touching the lamp with bare fingers can cause a faulty detector.
u Never touch the quartz bulb of the lamp with bare fingers.
u Clean a touched bulb with a lint free cloth and alcohol.
