BÜCHI Labortechnik AG Installation | 5
PrepChrom C­700 61/110
u Press Import or Export (5) to recover or save the current columns list
(files *.cart)
NOTE
The list can be exported as a .cart file.
5.7.5 Rack, setup
u Press Setup > Racks on the main menu.
• A window appears Do you want to Upload Rack Table? Press Yes to
modify the data and values of those that already exist.
u Press Add (1) to create new ones or press Delete (2) to remove any from
the list.
u To define a new rack, define all the following parameters
• code and name of the new rack set
• max. volume of one tube
• number of racks in the rack set
• number of tubes in the length of the rack (Y­axis)
• number of tubes in the width of the rack (X­axis)
• offsets and spacing as explained below.
Note
The needle offset (3) is preset, do not change!
• 5.7.6 Needle, offset [ } page 62]
