5 | Installation BÜCHI Labortechnik AG
48/110 PrepChrom C­700
u Tighten the knurled knob (1) to secure the upper holder.
5.5.2 Dry load column, preparation
u Set up a dry load column according to:
• 5.5.1 Flash/prep column, preparation [ } page 47]
5.5.3 Prep HPLC column, installation
Preliminary tasks
u Install the tube between the upper column holder and port no 3 of the 6­
way electrical valve.
u Install the tube between the lower column holder and the inlet of the
UV Detector module.
Tasks
u Tighten the lower knurled knob (2).
u Position the column (4) on the lower holder and tighten the PEEK
adapter (3).
NOTE
Hold the HPLC column during installation due to its weight.
