BUCHI PrepChrom C-700 - Manual (Page 60)

5 | Installation BÜCHI Labortechnik AG
60/110 PrepChrom C­700
5.7.3 Bottle, setup
u Press Setup > Bottles on the main menu.
u Adjust the value of each bottle by the up and down arrows (1).
NOTE
The minimum value is 100 mL.
u Select the desired solvent from the drop down menu or type the name into
the field (2).
u Press Ok to finish the bottle setup.
5.7.4 Column, setup
u Press Setup > Columns on the main menu.
u Press Load (1) to load the file buchi.csv which includes all the flash col­
umns from BUCHI.
u Press Add (2) to setup up a custom column if required.
u Press Delete (3) to remove columns that have been added
u Press Clean­Up (4) to remove all columns loaded from a database
