Print Formatting
77
7.0
Print Formatting
The 880 provides five print formats. Formats
GFMT
and
NFMT
will be printed based on the current mode of
operation when the
key is pressed (see Table 7-2 on page 78).
HDRFMT
can be inserted into any other print
format using the
formatting command.
SPFMT
is printed when a setpoint is satisfied if
PSHPRT
is set to
ON
or
WAITSS
in the setpoint configuration. The
ACCFMT
is printed if the accumulator is embedded and the print key is
pressed while viewing the accumulator value, or if a setpoint
PSHACM
is set to ON. If
PSHACM
is set to
ONQUIE
, it
will accumulate, but not print.
Each print format can be customized to include up to 1000 characters of information (300 for
HDRFMT
), such as
company name and address. Use the indicator front panel (
PFORMT
menu), EDP commands, or the Revolution
®
configuration utility to customize the print formats.
7.1
Print Formatting Commands
Table 7-1 lists commands that can be used to format the 880 print formats. Commands included in the format
strings must be enclosed between < and > delimiters. Any characters outside of the delimiters are printed as text.
Text characters can include any ASCII character that can be printed by the output device.
Command
Description
Ticket Format
GFMT/NFMT/
ACCFMT
SPFMT
Gross weight in displayed units (See notes 1 and 2 below)
Net weight in displayed units (See notes 1 and 2)
Tare weight in displayed units (See notes 1 and 2)
Accumulated weight in displayed units
Number of accumulator event (5-digit counter)
Time of last accumulator event
Date of last accumulator event
Setpoint captured value
Setpoint target value
Setpoint mode (gross or net label)
Setpoint name
Setpoint number
Setpoint preact value
Time
Date
Time and date
Unit ID number (See note 3)
Consecutive number (See note 3)
Ticket header (HDRFMT)
New line (nn = number of termination (
characters) (See note 4)
Space (nn = number of spaces) (See note 4)
Toggle weight data format (formatted/unformatted)
(See note 5)
Alibi Ticket Number
Table 7-1. Print Format Commands
