42 880 Technical/Service Manual
3.2.8 Ports Menu
SETUP
.... ....
COM
SWAP
FLDBUS USBCOM
....
PORTS
....
BYTE
BOTH
NONE
DVCNET PRFBUS
Address Address
number number
USB
MEM
ETHNET
LOAD SAVE?
ALL ?
CFG ?
CAL ?
See
Figure 3-14
See
Figure 3-15
Figure 3-13. Ports Menu Structure
Table 3-10. PORT Menu Parameters
PORT Menu
Parameter Choices Description
COM RS-232 and RS-485 Communications Port – see Figure 3-14
USBCOM USB Device Port – see Figure 3-14
ETHNET Ethernet TCP/IP Port – see Figure 3-15.
USB MEM USB Host Memory Device functions.
FLDBUS Field bus option card port when CompactCom board is installed – see FLDBUS
Sublevel below.
FLDBUS Sublevel
SWAP NONE
BYTE
BOTH Specifies byte-swapping used for the field bus card. For DeviceNet cards, this
parameter defaults to BYTE; for all other cards the default value is NONE.
DVCNET 63
1-64 DeviceNet option address
PRFBUS 126
1-126 Profibus option address
