Configuration 27
3.1.3 User Setup Menu
The 880 indicator can be configured using a series of menus accessed through the indicator front panel when the
indicator is in user setup mode or setup mode. Table 3-1 summarizes the functions of the user setup menu.
000000
000000
ACCUM
Displayed only
if turned on in
Scale Menu
AUDIT TARE SETPTS T & D ACCUM SETUP
000000
DATE TIME
No Access
unless the
jumper is
installed
VIEW CLR Y?
000000
See
Figure 3-7
See
Figure 3-6
See
Figure 3-18
Figure 3-2. 880 Menu Layout
Table 3-1. 880 Menu Summary
Menu User Menu Function
AUDIT Audit Trail Displays the legally relevant (LR) firmware version, configuration count and calibration count.
SETUP Setup Used to enter setup mode, if audit trail is enabled.
T&D Time and Date View and change time and date.
ACCUM Accumulator View or clear the current accumulator value, if enabled.
SETPTS Setpoints Configure setpoint values and ENABLE/DISABLE setpoints. Only configured setpoints will be
available.
TARE Tare View the current tare value.
