68 880 Technical/Service Manual
Calibration Menu
Table 6-5. CALIBR EDP Commands
Command Menu Description Choices / Range
SC.WZERO#1 WZERO Perform zero calibration n/a
SC.WSPAN#1 WSPAN Perform span calibration n/a
SC.LC.CD#1 n/a Raw count at zero -2147483646 to 2147483647
SC.LC.CW#1 n/a Raw count at span -2147483646 to 2147483647
SC.LC.CZ#1 n/a -2147483646 to 2147483647
SC.REZERO#1 REZERO Perform zero caibration n/a
SC.WLIN.C1#1 n/a Calibrate linearization point 1 n/a
SC.WLIN.C2#1 n/a Calibrate linearization point 2 n/a
SC.WLIN.C3#1 n/a Calibrate linearization point 3 n/a
SC.WLIN.C4#1 n/a Calibrate linearization point 4 n/a
SC.WLIN.C5#1 n/a Calibrate linearization point 5 n/a
SC.WLIN.F1#1 CAL 1 Raw count value for linearization point 1 -2147483646 to 2147483647
SC.WLIN.F2#1 CAL 2 Raw count value for linearization point 2 -2147483646 to 2147483647
SC.WLIN.F3#1 CAL 3 Raw count value for linearization point 3 -2147483646 to 2147483647
SC.WLIN.F4#1 CAL 4 Raw count value for linearization point 4 -2147483646 to 2147483647
SC.WLIN.F5#1 CAL 5 Raw count value for linearization point 5 -2147483646 to 2147483647
SC.WLIN.V1#1 WGT 1 Test weight value for linearization point 1 0.0 - 999999.0
SC.WLIN.V2#1 WGT 2 Test weight value for linearization point 2 0.0 - 999999.0
SC.WLIN.V3#1 WGT 3 Test weight value for linearization point 3 0.0 - 999999.0
SC.WLIN.V4#1 WGT 4 Test weight value for linearization point 4 0.0 - 999999.0
SC.WLIN.V5#1 WGT 5 Test weight value for linearization point 5 0.0 - 999999.0
SC.WVAL#1 WVAL Test weight value 0.00001 - 999999.0
Note
The menu items, CAL1 – CAL5 are used to do the calibration. A value cannot be keyed in.

The SC.WLIN.Fx#1 EDP commands can be used to view and edit the value but they do not perform the
calibration. Use the SC.WLIN.Cx#1 commands to perform the calibration.
Ports COM Menu
Table 6-6. PORTS (COM) EDP Commands
Command Menu Description Choices / Range
EDP.BAUD#1 BAUD Port baud rate 1200, 2400, 4800, 9600, 19200,
28800, 38400, 57600, 115200
EDP.BITS#1 BITS Port data bits and parity 8NONE, 7EVEN, 7ODD
EDP.ECHO#1 ECHO Specifies whether characters received by the
port are echoed back to the sending unit OFF, ON
EDP.EOLDLY#1 EOLDLY Port end-of-line delay in 0.1 sec intervals Range: 0 - 255
EDP.TYPE#1 TYPE Specifies RS-232 or RS-485 communication 232, 485
EDP.ADDRESS#1 ADDRES RS-485 address Range: 0 - 255
EDP.PRNMSG#1 PRNMSG Print message OFF, ON
EDP.RESPONSE#1 RESPNS Response OFF, ON
EDP.SFMT#1 SFMT Stream format Alphanumeric, max Length: 200
EDP.STOPBITS#1 STOP B Stop Bits 1, 2
EDP.TERMIN#1 TERMIN Termination character CR/LF, CR
EDP.TRIGGER#1 TRIGGE Selects the operation of the port COMAND, STRLFT, STRIND,
REMOTE
