Page 73

EDP Commands
67
Scales Menu
Table 6-3. Scales EDP Commands
Command
Menu
Description
Choices / Range
SC.ACCUM#1
ACCUM
Accumulator
OFF, ON
SC.DFTHRH#1
DFTHRH
Digital filter cutout threshold
0-99999
SC.DSPRATE#1
DSPRAT
Display Update Rate (in 0.1 sec intervals)
1-80
SC.DFSENS#1
DFSENS
Digital filter cutout sensitivity
LIGHT,MEDIUM,HEAVY
SC.GRADS#1
GRADS
Graduations
1 - 100000
SC.MOTBAND#1
MOTBAN
Motion Band (in divisions)
0-100
SC.OVRLOAD#1
OVRLOA
Overload
FS+2%
,
FS+1D
,
FS+9D
,
FS
SC.PWRUPMD#1
PWRUPM
Power Up Mode
GO, DELAY
SC.RANGE1.MAX#1
MAX1
Maximum weight for first range or interval
0.0 - 999999.0
SC.RANGE2.MAX#1
MAX2
Maximum weight for second range or interval
0.0 - 999999.0
SC.RANGE3.MAX#1
MAX3
Maximum weight for third range or interval
0.0 - 999999.0
SC.SMPRAT#1
SMPRAT
Sample Rate
7.5HZ, 15HZ, 30HZ
,
60HZ,
120HZ, 240HZ, 480HZ, 960HZ
SC.SPLIT#1
SPLIT
Specifies full range, multi-range, or
multi-interval
OFF, 2RNG, 3RNG, 2INTVL, 3INTVL
SC.SSTIME#1
SSTIME
Stand still time (in 0.1 sec intervals)
1 - 65535
SC.TAREFN#1
TAREFN
Tare Function
BOTH, NOTARE, PBTARE, KEYED
SC.THRESH#1
THRESH
Accumulator Zero Threshold
0-999999
SC.ZRANGE#1
ZRANGE
Zero range (in %)
0.0 - 100.0
SC.ZTRKBND#1
ZTRKBN
Zero track band (in divisions)
0.0 - 100.0
Format Menu
Table 6-4. FORMAT EDP Commands
Command
Menu
Description
Choices / Range
If SPLIT = 2RNG, 3RNG, 2INTVL, 3INTVL
SC.PRI.DECPNT#1
DECPNT1
Decimal point location for first range or interval
888888, 888880, 8.88888, 88.8888,
888.888, 8888.88, 88888.8
SC.SEC.DECPNT#1
DECPNT2
Decimal point location for second range or
interval
888888, 888880, 8.88888, 88.8888,
888.888, 8888.88, 88888.8
SC.TER.DECPNT#1
DECPNT3
Decimal point location for third range or
interval. Only available in 3RNG or 3INTVL
888888, 888880, 8.88888, 88.8888,
888.888, 8888.88, 88888.8
SC.PRI.DSPDIV#1
DDIV1
Range/Interval (1 division size)
1D, 2D, 5D
SC.SEC.DSPDIV#1
DDIV2
Range/Interval (2 division size)
1D, 2D, 5D
SC.TER.DSPDIV#1
DDIV3
Range/Interval (3 division size)
Only available in 3RNG or 3INTVL.
1D, 2D, 5D
If SPLIT = OFF
SC.PRI.DECPNT#1
DECPNT
Decimal point location (for primary units)
888888, 888880, 8.88888, 88.8888,
888.888, 8888.88, 88888.8
SC.PRI.DSPDIV#1
DSPDIV
Display divisions
1D, 2D, 5D
SC.PRI.UNITS#1
UNITS
Specifies primary units for displayed and
printed weight
LB, KG, OZ, TN, T, G, NONE
SC.SEC.DECPNT#1
DECPNT
Decimal point location (for secondary units)
888888, 888880, 8.88888, 88.8888,
888.888, 8888.88, 88888.8
SC.SEC.DSPDIV#1
DSPDIV
Display divisions (for secondary units)
1D, 2D, 5D
SC.SEC.UNITS#1
UNITS
Specifies secondary units for displayed and
printed weight
LB, KG, OZ, TN, T, G, NONE
