Appendix 97
Table 10-5 lists the sub-parameters available when configuring a scale using INDUST mode. The table includes the
default values of the INDUST sub-parameters and the effective (not configurable) values used by NTEP,
CANADA, OIML and NONE regulatory modes
Table 10-5. REGULA/INDUST Mode Parameters, Comparison with Effective Values of Regulatory Modes
REGULA/INDUST Parameter REGULA Mode
Parameter Description INDUST NTEP CANADA OIML NONE
SNPSHT Display or Scale weight source DISPLAY DISPLAY DISPLAY DISPLAY SCALE
ZTARE Remove tare on ZERO NO NO NO YES YES
KTARE Always allow keyed tare YES YES NO YES YES
MTARE Multiple Tare Action REPLAC REPLAC NOTHIN REPLAC REMOVE
NTARE Allow negative tare NO NO NO NO YES
CTARE Allow CLEAR tare to clear tare YES YES YES NO YES
PRTMOT Allow print while in motion NO NO NO NO YES
PRTPT Add PT to keyed tare print NO NO YES YES NO
OVRBAS Zero base for overload calculation CALIB CALIB CALIB SCALE CALIB
10.6 Data Formats
10.6.1 Stream Serial Data Format
If stream data transmission is configured for the communication ports (
STRLFT
or
STRIND
), by default the 880
sends data using the Rice Lake Weighing Systems serial data format shown in Figure 10-1:
ASCII 02
decimal
Polarity:
< space > = Positive
<–> = Negative
W eight: 7 digits, right-justified, dummy
zer o es, d ecimal point w ith no leadin g
zer oes except for leading zer o immediately
pr eceding the decimal point. Leading
zer oes transmitted as spaces.
L = pounds
K = kilogram s
T = tons (T , TN )
O = ounces
G = grams
< space > = NONE
G = Gr oss
N = Net
Status:
< space > = valid
I = Invalid
M = Motion
O = Over/under range
or
Z = Center zero
Figure 10-1. Stream Serial Data Format
SFMT parameter default – <2>
Note
Format can be changed, see Section 10.7.
The character values can be changed for the stream format tokens, see Table 6-10 on page 70.
If the COM port is set to TYPE = RS485, the port will not stream data, and cannot be used in a local/remote
application. See Section 10.6.3.
10.6.2 Print Output Serial Data Format
When print format is configured for the demand (print) port in the setup menus, the 880 uses a data string formatted
for a basic ticket printout. The particular print format printed depends on the indicator configuration. See
Section 7.0 for print formatting.
Use the EDP commands, Revolution
®
or the front panel to fully customize the print to work with a wide variety of
printers, and other remote equipment.
