74 880 Technical/Service Manual
Print Format Menu
The Menu items (except for HDRFMT) are listed by the format and the sub-parameters.
Table 6-17. Print Format EDP Commands
Command Menu Description Choices / Range
ACC.FMT ACCFMT | FMT Accumulator enabled and displayed, or
setpoint print operation with
PSHACCM=ON Alphanumeric, Max Length: 1000
ACC.PORT ACCFMT | PORT Accumulator print port COM, USBCOM, ETH-S, ETH-C, USBMEM, OFF
GFMT.FMT GFMT | FMT Normal mode, no tare in system Alphanumeric, Max Length: 1000
GFMT.PORT GFMT | PORT Normal mode, no tare in system, print port COM, USBCOM, ETH-S, ETH-C, USBMEM, OFF
HDRFMT1 HDRFMT Must be inserted into other print format Alphanumeric, Max Length: 300
NFMT.FMT NFMT | FMT Normal mode, tare in system Alphanumeric, Max Length: 1000
NFMT.PORT NFMT | PORT Normal mode, tare in system, print port COM, USBCOM, ETH-S, ETH-C, USBMEM, OFF
SPFMT.FMT SPFMT | FMT Setpoint print operation with PSHPRT=ON Alphanumeric, Max Length: 1000
SPFMT.PORT SPFMT | PORT Setpoint print port COM, USBCOM, ETH-S, ETH-C, USBMEM, OFF
Note
Note
See Section 7.2 on page 78 for detailed information.
Digital I/O Configuration Menu
Table 6-18. Digital I/O Configuration EDP Commands
Command Menu Choices / Range
DIO.b#s BIT x OFF, PRINT, ZERO, TARE, UNITS, CLEAR, DSPACC, DSPTAR, NT/GRS, CLRCN,
BATRUN, BATSTR, BATPAS, BATRST, BATSTP, OUTPUT
Digital inputs and outputs are specified by bit number (b = 1, 2, 3 or 4) and slot number (s = 0 or 1).
Analog Out Menu
Table 6-19. ALGOUT EDP Commands
Command Menu Description Choices / Range
ALG.MODE#1 MODE Specifies the weight data, gross or net, tracked by the
analog output GROSS, NET
ALG.OUTPUT#1 OUTPUT Specifies the output type 0-10V, 0-20MA, 4-20MA
ALG.ERRACT#1 ERRACT Error action FULLSC, HOLD, ZEROSC
ALG.MIN#1 MIN Minimum value tracked Range: 0 - 999999
ALG.MINNEG#1 MINNEG Specify ON if the minimum weight is a negative value OFF, ON
ALG.MAX#1 MAX Maximum value tracked Range: 0 - 999999
ALG.MAXNEG#1 MAXNEG Specify ON if the maximum weight is a negative value OFF, ON
