Appendix 95
10.2 Using the HARDWARE Command
The HARDWARE serial command can be used to verify that installed option cards are recognized by the system.
The HARDWARE command returns a three-digit card code, representing the card installed:
Table 10-2. HARDWARE Command Option Card Type Codes
Code Card Type
000 No card installed
085 Relay Card
153 Analog Output Card
170 CompactCom Card
If an installed card is not recognized (HARDWARE command returns code of 0), ensure that the card is seated
properly. Reinstall the card, if necessary, then cycle the power to read the configuration again. If the card is still not
recognized, try a different option card.
10.3 ERROR Commands Output
The XE and XEH commands return a representation of any existing error conditions as described in the following
table. If more than one error condition exists, the number returned is the sum of the values representing the error
conditions. The XE command returns the value as a decimal representation and the XEH command returns the
value as a hexadecimal representation.
Table 10-3. Error Commands Output
XE Error Code
(decimal) Description
XEH Error Code
(hexadecimal)
0 no errors 0x00000000
1 VIRGERR 0x00000001
2 PARMCHKERR 0x00000002
4 LOADCHKERR 0x00000004
8 PRINTCHKERR 0x00000008
16 ENVRAMERR 0x00000010
32 ENVCRCERR 0x00000020
64 BATTERYERR 0x00000040
32768 GRAVERR 0x00008000
65536 ADPHYSICALERR 0x00010000
131072 TAREERR 0x00020000
262144 EACCOVER 0x00040000
524288 STRINGERR 0x00080000
1048576 RESERVED_PF 0x00100000
2097152 RTCERR 0x00200000
4194304 MISSINGHWERR 0x00400000
8388608 CFGCONFLICTERR 0x00800000
16777216 UNRECOVERABLEERR 0x01000000
