Rice Lake 880 Performance Series Indicator/Controller Technical/Service Manual - Manual (Page 31)

Table 2-6. Panel Mount Replacement Parts
Item No. Part No. Description (Quantity) Qty
151674 Display Assembly, 880 Panel Mount (Includes items 1-7) Ref
1 131740 Overlay, Membrane Switch 1
2 151663 Faceplate, Display 880 1
3 151667 Gasket, Faceplate 880 1
4 131598 Board Assy, 880 LED Disp. 1
5 14822 Screw, Mach 4-40NC x 1/4 4
6 156439 Backer, Plate With DIN 1
7 14621 Nut, Kep 6-32NC HEX 4
8 151668 Cable Assy, Controller to Display 1
151672 Controller, 880 Panel (Includes items 9-20) Ref
9 14838 Screw, Mach 6-32NC x 1/4 2
10 65685 Washer, Flat .375OD .156ID 2
11 151664 Hook, Left DIN Rail Clip 1
151665 Hook, Right DIN Rail Clip 1
12 131745 Bracket, DIN Rail Clip 880 1
13 153856 Screw, Mach 6-32NCx1/4 8
14 151661 Enclosure, CPU 880 1
15 131599 Board Assy, 880 Power, AC 1
151675 Board Assy, 880 Power, DC 1
16 152666 BackPlate, CPU Relay 1
152373 BackPlate, Relay Option 1
156668 BackPlate, Analog Option 1
156669 BackPlate, CompactCom Options 1
17 14822 Screw, Mach 4-40NC x 1/4 8
18 69291 Battery, 3v Coin Lithium 1
19 131597 Board Assy, CPU 880 PNL 1
20 154762 Cable Assy, CPU Board To 1
152235 Parts Kit, AC Power 880 (Includes items below) 1
153647 Parts Kit, DC Power 880 (Includes items below)
NS 152334 Conn, 3 Pos Screw Terminal (AC Option) 1
15888 Terminal Block, 3 position (DC Option)
NS 153873 Conn, 3 Pos Screw Terminal 1
NS 153883 Conn, 6 Pos Screw Terminal 2
NS 94422 Label, Capacity .40 x 4.63 1
* Additional parts included in parts kit. See Section 2.1.1 on page 5 for additional parts information.
CAUTION
Installation 25
There is a risk of explosion if battery is replaced by an incorrect type.
