GROSS, NET, -GROSS, -NET, and %REL type setpoints

SP.KIND#n=GROSS, NET, -GROSS, -NET, or %REL
SP.ACCESS#n
SP.BNDVAL#n (if TRIP INBAND or OUTBAND only)
SP.BRANCH#n (if BATSEQ is ON)
SP.CLRACCM#n
SP.CLRTARE#n
SP.DIGOUT#n
SP.HYSTER#n (if TRIP HIGHER or LOWER only)
SP.BATSEQ#n
SP.NAME#n
SP.PCOUNT#n (if PREACT is LEARN only)
SP.PREACT#n (if TRIP HIGHER or LOWER only)
SP.PREADJ#n (if PREACT is LEARN only)
SP.PRESTAB#n (if PREACT is LEARN only)
SP.PREVAL#n (if PREACT is ON or LEARN only)
SP.PSHACM#n
SP.PSHPRT#n
SP.PSHTAR#n
SP.RELNUM#n (for %REL setpoints only)
SP.SENSE#n
SP.SLOT#n
SP.TRIP#n
SP.VALUE#n

PAUSE type setpoints

SP.KIND#n=PAUSE
SP.ACCESS#n
SP.DIGOUT#n
SP.NAME#n
SP.SENSE#n
SP.SLOT#n

DELAY type setpoints

SP.KIND#n=DELAY and AUTJOG
SP.ACCESS#n
SP.CLRACCM#n
SP.CLRTARE#n
SP.DIGOUT#n
SP.NAME#n
SP.PSHACM#n
SP.PSHPRT#n
SP.PSHTAR#n
SP.SENSE#n
SP.SLOT#n
SP.VALUE#n

WAITSS type setpoints

SP.KIND#n=WAITSS
SP.ACCESS#n
SP.CLRACCM#n
SP.CLRTARE#n
SP.DIGOUT#n
SP.NAME#n
SP.PSHACCM#n
SP.PSHPRINT#n
SP.PSHTARE#n
SP.SENSE#n
SP.SLOT#n

COUNTR type setpoints

SP.KIND#n=COUNTR
SP.ACCESS#n
SP.BRANCH#n
SP.DIGOUT#n
SP.NAME#n
SP.SENSE#n
SP.SLOT#n
SP.VALUE#n
SP.KIND#n=TIMER and CONCUR
SP.ACCESS#n
SP.DIGOUT#n
SP.END#n
SP.NAME#n
SP.SLOT#n
SP.START#n
SP.SENSE#n
SP.VALUE#n
