44 880 Technical/Service Manual
COM Menu
Parameter Choices Description
TRIGGE COMAND Setting Trigger to command allows opration of EDP commands and can print.
STRLFT Stream Legal for Trade data – data is updated at the configured display update rate.
STRIND Stream Industrial scale data – data is updated at the configured sample rate.
REMOTE Configures the port to operate as a serial scale input. See “Menu Structure if
TRIGGE is set to REMOTE” below. (Not available in USBCOM)
Note
When in STRLFT, STRIND and REMOTE, if the COM port is set to TYPE = RS485, the
port will not stream data, and cannot be used in a local/remote application. See
Section 10.6.3.
BAUD 9600
19200
28800
38400
57600
115200
1200
2400
4800 Port baud rate. (Not available in USBCOM)
BITS 8NONE
7EVEN
7ODD Port data bits and parity. (Not available in USBCOM)
STOP B 1
2 Stop Bits – selects the number of stop bits transmitted and the number of stop bits
expected to be received by the port. (Not available in USBCOM)
TERMIN CR/LF
CR Termination – selects the termination character(s) for data sent from the port.
ECHO ON
OFF Specifies whether characters received by the port are echoed back to the sending
unit.
RESPNS ON
OFF Response – specifies whether the port transmits replies to serial commands
EOLDLY 000000 End of Line Delay - specifies, in 0.1 second intervals, the delay between transmitted
lines of data.
TYPE 232
485 Specifies the protocol for the COM port. (Not available in USBCOM)
ADDRES 0-255 If TYPE is 485, specifies the RS-485 address. (Not available in USBCOM)
PRNMSG OFF
ON Print message – displays a message when a print is transmitted on this port.
SFMT <2>


Stream format – specifies the stream format used for streaming output of scale data
(TRIGGE=STRLFT or STRIND) or specifies the expected input for a serial scale
(TRIGGE=REMOTE).
Menu Structure if TRIGGE is set to REMOTE
TRIGGE REMOTE Configures the port to operate as a serial scale input.
BAUD 9600
19200
28800
38400
57600
115200
1200
2400
4800 Port baud rate.
Table 3-11. COM and USBCOM Menu Parameters
