Configuration 45
3.2.10 Ethernet Communications Menu
SETUP
.... ....
....
PORTS
....
ETHNET
DHCP
ON
OFF
IPADRS
xxx.xxx.xxx.xxx
NETMSK
xxx.xxx.xxx.xxx
DFTGWY
xxx.xxx.xxx.xxx
DNSPRI
xxx.xxx.xxx.xxx
DNSSEC
xxx.xxx.xxx.xxx
MAC SERVER
PORT
number
TRIGGE
STRLFT
COMAND
STRIND
TERMIN
CR/LF
CR
EOLDLY
number
TIMOUT
number
SFMT
ECHO
OFF
ON
ON
OFF
RESPNS
RMOTIP TRIGGE
STRLFT
COMAND
STRIND
TERMIN
CR/LF
CR
EOLDLY
number
TIMOUT
number
ECHO
OFF
ON
ON
OFF
RESPNS
RMOTPT
number
SFMT
ALPHA/NUM
ALPHA/NUM
xxx.xxx.xxx.xxx
xx.xx.xx.xx.xx.xx
CLIENT
Figure 3-15. Ethernet Menu Structure
BITS 8NONE
7EVEN
7ODD Port data bits and parity.
STOP B 1
2 Stop Bits – selects the number of stop bits transmitted and the number of stop bits
expected to be received by the port
PRNMSG OFF
ON Print message – displays a message when a print is transmitted on this port.
SFMT <2>


Stream format – specifies the expected input for the serial scale.
COM Menu
Parameter Choices Description
Table 3-11. COM and USBCOM Menu Parameters (Continued)
