Note
76 880 Technical/Service Manual
Digital I/O Control Menu
Table 6-21. Digital I/O Control EDP Commands
Command Function
DON.b#s Set digital output on (active) at bit b, slot s
DOFF.b#s Set digital output off (inactive) at bit b, slot s
Digital inputs and outputs are specified by bit number (b = 1, 2, 3 or 4) and slot number (s = 0 or 1).
The DON/DOFF commands will only control the state of the a slot/bit that is defined as an OUTPUT in the
configuration menu.
6.1.6 ERROR Commands Output
The XE and XEH commands return a representation of any existing error conditions as described Table 10-3 on
page 95.
6.1.7 Batching Control Commands
Table 6-22. Batching Control Commands
Command Function
BATSTART Batch start. If the BATRUN digital input is active (low) or not assigned, the BATSTART command can
be used to start the batch program.
If the BATRUN is inactive (high), the BATSART command will reset the batch program to the first
batch step.
BATSTOP Batch stop. Stops the batch program at the current batch step and turns off all associated digital
outputs.
BATPAUSE Batch pause. Stops the batch program at the current step. All digital outputs set on by the current
step (except for those set by concur setpoints) are set off. The BATSTR digital input or BATSTART
serial command can be used to restart the batch program at the current step.
BATRESET Batch reset. Stops the program and resets the batch program to the first batch step. Run the
BATRESET command after making changes to the batch configuration.
