70 880 Technical/Service Manual
Ports – USBCOM Menu
Table 6-9. PORTS – USBCOM EDP Commands
Command Menu Description Choices / Range
EDP.ECHO#2 ECHO Specifies whether characters received by the port are
echoed back to the sending unit. OFF, ON
EDP.EOLDLY#2 EOLDLY Port end-of-line delay Range: 0 - 255
EDP.PRNMSG#2 PRNMSG Displays print message OFF, ON
EDP.RESPONSE#2 RESPNS Specifies whether the port transmits replies to serial
commands. OFF, ON
EDP.SFMT#2 SFMT Stream format Alphanumeric, max Length: 200
EDP.TERMIN#2 TERMIN Termination character CR/LF, CR
EDP.TRIGGER#2 TRIGGE Selects the operation of the port COMAND, STRLFT, STRIND
Stream Tokens Menu
Table 6-10. Stream Tokens EDP Commands
Command Description Default Choices / Range
STR.GROSS String transmitted for the token for gross weight G Alphanumeric, Max Length: 8
STR.INVALID String transmitted for the token when weight is invalid I Alphanumeric, Max Length: 2
STR.MOTION String transmitted for the token when scale is in motion M Alphanumeric, Max Length: 2
STR.NEG Character transmitted for the
token when the weight is
negative
- NONE, SPACE, -
STR.NET String transmitted for the token for net weight N Alphanumeric, Max Length: 8
STR.OK String transmitted for the token when the scale is ok “ “ Alphanumeric, Max Length: 2
STR.POS Character transmitted for the
token when the weight is
positive
SPACE NONE, SPACE, +
STR.PRI String transmitted for the token for primary units L Alphanumeric, Max Length: 8
STR.RANGE String transmitted for the token when the scale is out of
range O Alphanumeric, Max Length: 2
STR.SEC String transmitted for the token for secondary units K Alphanumeric, Max Length: 8
STR.TARE String transmitted for the token for tare weight T Alphanumeric, Max Length: 8
STR.ZERO String transmitted for the token when the scale is at
center of zero Z Alphanumeric, Max Length: 2
Feature Menu
Table 6-11. Feature EDP Commands
Command Menu Description Choices / Range
CONSNUM CURVAL Consecutive numbering 0 – 999999
CONSTUP RESVAL Consecutive number startup value 0 – 999999
DECFMT DECFMT Decimal format DOT, COMMA
GRAVADJ LOCALE Locale - must be enabled for latitude and elevation OFF, ON
LAT.LOC LATUDE Latitude (Locale must be set to ON) 0-90
ELEV.LOC ELEVAT Elevation (Locale must be set to ON) -9999-9999
UID UID Unit ID Alphanumeric, Max Length: 6
ETH.SERVER.TIMEOUT SERVER | TIMOUT Inactivity disconnect timeout – connection is
dropped after a specified period (in seconds) of
inactivity. Setting the value to 0 disables the
parameter Range 0-65535
ETH.SERVER.TRIGGER SERVER | TRIGGE Selects the operation of the Server Ethernet
port COMAND, STRLFT,
STRIND
Table 6-8. PORTS – Ethernet EDP Commands (Continued)
