5.1 Setting up and connecting the instruments
785 DMP Titrino
151
5.1.2 Connection of a printer
A variety of printers can be connected to the RS232 interface of the
736 GP Titrino. If you connect a printer other than one of those men-
tioned below, ensure that the Epson mode is emulated or that it
uses the international character set following the IBM Standard Table
437 and IBM-compatible graphics control characters.
If a balance is connected at the same COM of the Titrino as a
printer, you need the 6.2125.010 + 6.2125.030 Adapters.
Printer
Cable
Settings on Titrino
Settings on Printer
Seiko
DPU-414
6.2134.110
baud rate:
9600
data bit:
8
stop bit:
1
parity:
none
handshake:
HWs
send to:
Seiko
none
Seiko
DPU-411
6.2125.020
+
6.2125.010
baud rate:
9600
data bit:
8
stop bit:
1
parity:
none
handshake:
HWs
send to:
Seiko
Citizen
iDP562 RS
6.2134.050 baud rate:
9600
data bit:
8
stop bit:
1
parity
none
handshake:
HWs
send to:
Citizen
Epson LX-
300
6.2134.050 as above but
send to:
Epson
see printer manual
HP Desk Jet
with serial
interface
6.2134.050 baud rate:
9600
data bit:
8
stop bit:
1
parity
none
handshake:
HWs
send to:
HP
HP Desk Jet
with parallel
interface
6.2125.020
+
6.2125.010
+
2.145.0300
Parallel-
Serial-
Converter
baud rate:
9600
data bit:
8
stop bit:
1
parity
none
handshake:
HWs
send to:
HP
see printer manual
ON
1
2
3
4
5
6
7
8
9
10
SSW1
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
DIP02
DIP01
B:
A4 paper
