3.2. Remote control commands
785 DMP Titrino
120
• L6 is the line of the activate pulse. An active line 6 is set to
"inactive" by the activate pulse.
• L5 is the error line. It is continuously controlled by the Titrino
program and can therefore not be set freely.
Line assignments in Titrino program:
L0
Ready, inactive state
L1 Conditioning OK
L2 Titration in progress
L3 EOD (End Of Determination)
L4 Can be set in TIP
L5 Error
L6 Activate pulse + can be set in TIP
L7 Buret volume pulses
L8 Remote box active
L12 Sample size out of limits
L13 Result out of limits
.ResetLines: Lines are set to the inactive status (= high).
3.2.2.114. Assembly.Stirrer ON, OFF
Switching stirrer ON/OFF.
3.2.2.115. Setup.Comport 1, 2, 1&2
Selects the Titrino COM for the output of automatic info:
&Setup.Keycode
&Setup.Trace
&Setup.SendMeas
&Setup.AutoInfo
3.2.2.116. Setup.Keycode ON, OFF
ON means the key code of a key pressed on the Titrino is outputted. The key
code comprises 2 ASCII characters; table of the keys with their code, see
page 140. A keystroke of key 11 is sent as follows:
#11
The beginning of the message is marked by a space (ASCII 32).
3.2.2.117. Setup.Tree.Short ON, OFF
Setup.Tree.ChangedOnly ON, OFF
Definition of the type of answer to $Q.
.Short:
With "ON", each path is sent with only the necessary amount of
characters in order to be unequivocal (printed in bold in this manual). A com-
bination of .Short and .ChangedOnly is not possible.
.ChangedOnly:
Sends only the changed values, i.e. values which have
been edited. All paths are sent absolute, i.e. from the root.
3.2.2.118. Setup.Trace ON, OFF
