3.2. Remote control commands

785 DMP Titrino

116

Info.SiloCalc.C26.Std

read only

Info.SiloCalc.C26.RelStd

read only

for .C27 as for .C26

The current values from the silo calculations. C26 is the mean value out of the
C24 variables; C27 comes from C25.
$Q sends:
C24.Name: Name of the assigned value

"RS1"

C24.Value: Value

"2.222"

C24.Unit: Unit of the assigned value

"%"

C26.ActN: Number of single results

"3"

C26.Mean: Mean (decimal places as for the result itself)

"3.421"

C26.Std: Standard deviation (decimal places as for the result + 1) "0.0231"
C26.RelStd: Relative standard deviation (in %, 2 decimal places)

"0.14"

3.2.2.100. Info.ActualInfo.Inputs.Status

read only

Info.ActualInfo.Inputs.Change

read only

Info.ActualInfo.Inputs.Clear

$G

Info.ActualInfo.Outputs.Status

read only

Info.ActualInfo.Outputs.Change

read only

Info.ActualInfo.Outputs.Clear

$G

Status sends the current status of the I/O lines, Change sends the information
regarding whether a change in status of a line has taken place since the last
clearing, Clear clears the change information. For the output, there is a con-
version from binary to decimal, e.g.

| 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 1 | 0 | 1 | 0 |

Line No.

| 13| 12| 11| 10| 9 | 8 | 7 | 6 | 5 | 4 | 3 | 2 | 1 | 0 |

Output: 2

1

+ 2

3

= "10"

1 means ON or change; 0 means OFF or no change.
The lines are assigned as follows (see also pages 166ff):
Inputs:

Outputs:

0

Start (pin 21)

0

Ready (pin 5)

1

Stop (pin 9)

1

Cond. ok (pin 18)

2

Enter (pin 22)

2

Titration (pin 4)

3

Clear (pin 10)

3

EOD (pin 17)

4

Smpl Ready (pin 23)

4

L4 in TIP (pin 3)

5

pin 11

5

Error (pin 16)

6

pin 24

6

Activate, L6 in TIP (pin 1)

7

pin 12

7

Pulse for recorder (pin 2)

8

not used

(pin 6)

9

not used

(pin 7)

10

not used

(pin 8)

11

not used

(pin 13)

12

Smpl size out

(pin 19)

13

Result out

(pin 20)

3.2.2.101. Info.ActualInfo.Assembly.CyclNo

read only

$Q sends the current cycle number of the voltage measurement cycle, e.g.
"127". From the cycle number and the cycle time (see 3.2.2.108), a time
frame can be set up.
