92 Rockwell Automation Publication D2-3518-3 - May 2013
Chapter 9
Note that the manual reference command can override the reference control
source.
Scales the upper value of the Speed Ref B Sel (93) selection when the source is an
analog input.
Scales the lower value of the Speed Ref B Sel (93) selection when the source is an
analog input.
Specifies the manual speed reference source when a digital input is configured for
auto/manual and manual reference mode is active.
ATTENTION: Removing and replacing the OIM while the drive is running may
cause an abrupt speed change if the OIM is the selected reference source. The
drive will ramp to the reference level provided by the OIM at the rate specified in
Accel Time 1 (140), Accel Time 2 (141), Decel Time 1 (142), and Decel Time 2
(143). Be aware that an abrupt speed change may occur depending upon the
new reference level and the rate specified in these parameters. Failure to
observe this precaution could result in bodily injury.
94 Speed Ref B Hi
Range: -/+Maximum Speed [0.1 Hz]
Default: Maximum Speed
Access: 0 Path: Speed Command > Speed References
See also: 82
95 Speed Ref B Lo
Range: -/+Maximum Speed [0.1 Hz]
Default: 0.0 Hz
Access: 0 Path: Speed Command > Speed References
See also: 81
96 TB Man Ref Sel
Range: 1 = Analog In 1
2 = Analog In 2
3...8 = Reserved
9 = MOP Level
Default: 2 = Analog In 1
Access: 0 Path: Speed Command > Speed References
See also: 97, 98
