Rockwell Automation Liqui-Flo V2.0 AC Drive User Manual
Page 125
Rockwell Automation Publication D2-3518-3 - May 2013
125
Chapter 9
The hottest measured inverter IGBT module temperature is displayed as
x.x degrees C.
Accumulated percentage of drive overload. Continuously operating the drive
over 100% of its rating increases this value to 100% and causes a Drive OverLoad
fault (fault 64).
Accumulated percentage of motor overload. Continuously operating the motor
over 100% of Motor OL Amps (48) increases this value to 100% and causes a
Motor OverLoad fault (fault 7).
Displays the imbalance in current between motor phases.
If the imbalance count remains over inverter Imbalance Limit (49) for more than
inverter Imbalance Time (50), the Motor I Imbalance fault (fault 37) occurs.
The imbalance in amps is calculated as the larger of:
(largest phase current) – (average phase current), or
(average phase current) – (smallest phase current).
218
Invtr Base Temp
Range:
-/+100 °C [0.1 °C]
Default:
Read Only
Access:
1
Path: Utility > Diagnostics
See also:
219
Drive OL Count
Range:
0.0...100.0% [0.1%]
Default:
Read Only
Access:
1
Path: Utility > Diagnostics
See also:
150
220
Motor OL Count
Range:
0.0...100.0 [1.0%]
Default:
Read Only
Access:
1
Path: Utility > Diagnostics
See also:
47, 48
221
Imbalance Count
Range:
0.0...100.0 [1.0%]
Default:
Read Only
Access:
1
Path: Utility > Diagnostics
See also:
22...24, 49, 50
