Rockwell Automation Publication D2-3518-3 - May 2013 61
Chapter 8
Utility Drive Memory Param Access Lvl 196 Save to User Set 199 Drive Checksum 203
Reset to Defaults 197 Reset Meters 200 –
Load Frm Usr Set 198 Language 201 –
Status Drive Alarm 211 Dig In Status 216 –
Start Inhibits 214 Dig Out Status 217 –
Diagnostics Fault Frequency 220 Fault Amps D 225 Testpoint 1 Data 235
Fault Amps R 221 Fault Volts Vdc 226 Testpoint 2 Sel 236
Fault Amps S 222 Fault Volts Q 227 Testpoint 2 Data 237
Fault Amps T 223 Fault Volts D 228 –
Fault Amps Q 224 Testpoint 1 Sel 234 –
Fault Queue Fault Config 238 Fault To Invertr 241 Fault 1 Code...
Fault 4 Code 243
245
247
249
Fault Clear 240 Power Up Marker 242 Fault 1 Time...
Fault 4 Time 244
246
248
250
Communications In Data Links IOC Redir Time 300 Service 302 302 –
IOC Redir Max 301 Service 303 303 –
Inputs & Outputs Temperatures etc Rct IGBT Tmp Top 345 Rct Coldplt Tmp 349 Rct PS -12V 353
Rct IGBT Tmp Up 346 Rct Ambient Tmp 350 Rct I/O ID V 354
Rct IGBT Tmp Low 347 Rct PS Tmp 351 –
Rct IGBT Tmp Bot 348 Rct PS +12V 352 –
File Group Parameters
