Rockwell Automation Liqui-Flo V2.0 AC Drive User Manual
Page 192
192
Rockwell Automation Publication D2-3518-3 - May 2013
Chapter 9
Displays the measured temperature of the top rectifier IGBT power module in
degrees C.
This parameter is only present on Frame 4 drives. All such drives should have
firmware version numbers in the 2.x series.
Displays the measured temperature of the upper rectifier IGBT power module
in degrees C.
This parameter is only present on Frame 4 drives. All such drives should have
firmware version numbers in the 2.
x series.
Displays the measured temperature of the lower rectifier IGBT power module
in degrees C.
This parameter is only present on Frame 4 drives. All such drives should have
firmware version numbers in the 2.
x series.
Displays the measured temperature of the bottom rectifier IGBT power module
in degrees C.
This parameter is only present on Frame 4 drives. All such drives should have
firmware version numbers in the 2.
x series.
345
Rct IGBT Tmp Top
Range:
-3276.8...3276.7 °C
Default:
Read Only
Access:
1
Path: Inputs & Outputs > Temperature etc
See also:
346, 347, 348
346
Rct IGBT Tmp Up
Range:
-3276.8...3276.7 °C
Default:
Read Only
Access:
1
Path: Inputs & Outputs > Temperature etc
See also:
345, 347, 348
347
Rct IGBT Tmp Low
Range:
-3276.8...3276.7 °C
Default:
Read Only
Access:
1
Path: Inputs & Outputs > Temperature etc
See also:
345, 346, 348
348
Rct IGBT Tmp Bot
Range:
-3276.8...3276.7 °C
Default:
Read Only
Access:
1
Path: Inputs & Outputs > Temperature etc
See also:
345, 346, 347
