Rockwell Automation Liqui-Flo V2.0 AC Drive User Manual
Page 146
146
Rockwell Automation Publication D2-3518-3 - May 2013
Chapter 9
Selects the mode for the user-configurable analog output.
See
AC Line I/O Board Description (Frame 3 Only) on page 25
through
Combined I/O Board Description (Frame 4 Only) on page 29
for a description
of I/O hardware that is present on this drive and is controlled by the inverter.
Figure 66 - Anlg Out Config (340)
For Frame 4 drives only (firmware versions 2.x), the actual mode of the user-
configurable analog output depends on the value of this parameter and on the
capabilities of the analog output hardware on the Combined I/O board. The
units (V or mA) displayed for the Analog Out Hi and Analog Out Lo
parameters are an accurate indication of the actual mode of the analog output.
Selects whether the signed value or absolute value of a parameter is used before
being scaled to drive the user-configurable analog output.
See
AC Line I/O Board Description (Frame 3 Only) on page 25
through
Combined I/O Board Description (Frame 4 Only) on page 29
for a description
of I/O hardware that is present on this drive and is controlled by the inverter.
340
Anlg Out Config
Range:
Default:
1
Access:
1
Path: Inputs & Outputs > Analog Outputs
See also:
341
Anlg Out Absolut
Range:
See
Default:
See
Access:
1
Path: Inputs & Outputs > Analog Outputs
See also:
342
x
x
x
1
x
x
x
x
x
x
x
x
x
x
x
x
0
0
1
1
2
3
4
5
6
7
8
9
11
12
13
14
15
1 =Current
0 =Voltage
x =Reserved
Bit #
Factory Default Bit Values
Analog Out
Nibble 1
Nibble 2
Nibble 3
Nibble 4
