Sets the on delay time for the user-configurable digital output 2. This is the time
between the occurrence of a condition and activation of the digital output.
See AC Line I/O Board Description (Frame 3 Only) on page 25 through
Combined I/O Board Description (Frame 4 Only) on page 29 for a description
of I/O hardware that is present on this drive and is controlled by the inverter.
Sets the off delay time for inverter digital output 2. This is the time between the
disappearance of a condition and de-activation of the digital output.
See AC Line I/O Board Description (Frame 3 Only) on page 25 through
Combined I/O Board Description (Frame 4 Only) on page 29 for a description
of I/O hardware that is present on this drive and is controlled by the inverter.
Rectifier Parameters
The input line frequency is displayed as
x.x Hz.
The RMS input phase current I
r is displayed as x.x A.
386 Dig Out2 OnTime
Range: 0.00...600.00 sec [0.01 sec]
Default: 0.00 sec
Access: 1 Path: Inputs & Output > Digital Outputs
See also: 384
387 Dig Out2 OffTime
Range: 0.00...600.00 sec [0.01 sec]
Default: 0.00 sec
Access: 1 Path: Inputs & Output > Digital Outputs
See also: 384
1 Line Frequency
Range: 0.0...63.0 Hz [0.1 Hz]
Default: Read Only
Access: 0 Path: Monitor > Metering
See also:
2 Input Current R
Range: 0.0...3276.7 A [0.1 A]
Default: Read Only
Access: 0 Path: Monitor > Metering
See also:
