Rockwell Automation Publication D2-3518-3 - May 2013 79
Chapter 9
Displays a fault from the rectifier. The rectifier writes a fault code into this
parameter through a data link.
Set to match the type of motor connected: Induction, Synchronous Reluctance,
or Synchronous Permanent Magnet.
Set to the motor nameplate rated volts. The motor nameplate base voltage
defines the output voltage when operating at rated current, rated speed, and rated
temperature.
Set to the motor nameplate rated full load amps. The motor nameplate FLA
defines the output amps when operating at rated voltage, rated speed, and rated
temperature. It is used in the motor thermal overload and in the calculation of
slip.
35 Rctfr Fault
Range: 0...299
Default: Read Only
Access: 1 Path: Monitor > Application
See also:
40 Motor Type
Range: 0 = Induction
1 = Synchr Reluc
2 = Synchr PM
Default: 0 = Induction
Access: 1 Path: Motor Control > Motor Data
See also:
41 Motor NP Volts
Range: 0.0 to Drive Rated Volts [0.1V AC]
Default: Based on Drive Type
Access: 0 Path: Motor Control > Motor Data
See also:
42 Motor NP FLA
Range: 0.0 to Rated Amps x 2 [0.1 A]
Default: Based on Drive Type
Access: 0 Path: Motor Control > Motor Data
See also: 47, 48
