Rockwell Automation Publication 6000-IN007A-EN-P - October 2014 93
Special Function Parameter Settings Appendix C
Analog Input Relevant parameter: P205, P206
3/3.3 kV and 6/6.6 kV drives use the same VSB board.
Set P205 and P206 according to the following table
.
Stop Mode Relevant parameter: P24, P252, P253
Description: the drive has two ways to stop the drive, ramp down or coast stop.
Instruction: P24=1 to select coast stop, P24=0 to select ramp down.
If P24=1, the output will stop immediately, so the motor will stop by inertance. If
P24=0, the output will stop the from the set frequency to 0 Hz. When the
frequency=P252*rated frequency (P252 is a percentage value), the system will be
locked.
To restart the drive if coast stop was selected, wait until it stops before restarting.
The time needed is:
Flying Start Function Relevant parameter: P113, P114, P115, P416, P417, P438, P457, P459,
P463, K5
Description: The PowerFlex 6000 has three flying start modes:
• search the frequency from set frequency
• search the frequency from the last stop frequency added 5 Hz
• search from the maximum frequency.
Instruction: the flying start feature identifies the motor speed based on the
output current.
Voltage Level (kV) VSB proportion (kV:V) P205, P206
3 3:5 199.99
3.3 3:5 181.82
4.16 3:5 144.23
6 6:5 199.99
6.6 6:5 181.82
10 10:5 199.99
P253
FrequencyBeforeStop
MaximumFrequency
---------------------------------------------------------- 
