Rockwell Automation 6000 PowerFlex Medium Voltage Variable Frequency Drive Commissioning Manual User Manual
Page 26
26
Rockwell Automation Publication 6000-IN007A-EN-P - October 2014
Chapter 2
Preparation and Inspection
8.
Disconnect the control cable of HECS.
Figure 7 - Hall Effect Current Sensor
9.
Disconnect the HMI and Control Board power cables.
Figure 8 - Back of HMI
Control Cable
HECS
Control Board Power Cables
HMI Power Cable
