Table 3 - Inspect Drive Components Checklist

Bypass Cabinet (if supplied)

Isolation Transformer Cabinet

Power Module Cabinet

Low Voltage Control Cabinet

Front

Door:
Pilot Lights
Voltage Indicator Relay
Cabinet:
Insulators
Switch assemblies
Vacuum contactors
Mechanical linkages

Door:
Transformer Temperature monitor
LV Cabinet components

Fan control circuit breakers

Cabinet:
Transformer Plastic Baffle
Outgoing Motor Power Cable standoffs on
Cabinet Sidesheet

(1)

Outgoing Motor Power Cable Terminal
Insulators on transformer

(1)

Voltage Sensing Board
Incoming Line Power Cable Terminal Insulators
on transformer
Motor Cable Braces
Fixed Mounted Power Module Configuration:
Transformer Secondary Windings (2 sets)

Inspect nomex wrap
Verify windings from core are undamaged
Check for debris in top of core

Fixed Mounted Power Module Configuration:
Power Module retaining tabs
Check for debris
Output Bus Supports
Fuse Mounting Supports
Drawout Power Module Configuration:
Support frame
Power Modules

Door:
Pilot lights
Push buttons
Selector switches
HMI
Interface board (on the back of the LV door)
Panel:
DIN rail mounted components
UPS
Fiber optic cables
PLC
Control Unit

Rear

Fixed Mounted Power Module Configuration:
Transformer Secondary Windings (1)

Inspect nomex wrap
Verify windings from core are undamaged
Check for debris in top of core

Drawout Power Module Configuration:
Transformer Secondary Windings (3)

Inspect nomex wrap
Verify windings from core are undamaged
Check for debris in top of core

Fixed Mounted Power Module:
Heat sink

Verify orientation relative to barrier plates

Drawout Power Module:
Power In/Power Out connections

UPS connections

(1) Motor Cable terminations could be on the transformer structure or cabinet sidesheet, depending on the power rating.
