Rockwell Automation 6000 PowerFlex Medium Voltage Variable Frequency Drive Commissioning Manual User Manual
Page 63
Rockwell Automation Publication 6000-IN007A-EN-P - October 2014
63
Commissioning
Chapter 3
Press
to enter password details. Press
when finished.
3.
Press
to
login.
4.
Press ,
and
press .
5.
Press the P007 parameter field to enter the number of power cells per
phase, and press
.
6.
Press the P224 parameter field.
7.
Change the value from 120 to 80. Press
, and press
.
8.
Press
to
exit
P Parameter Settings
,
to
confirm
Setup has logged out, and
to return to the Main Interface
Screen.
WARNING: Do NOT press Reset. This will reset all factory-set parameters.
WARNING: Remove the temporary jumper (X1-117, X1-119) in the LV Control
Cabinet, which was installed to enable the Control System Test.
