70

Rockwell Automation Publication 6000-IN007A-EN-P - October 2014

Chapter 4

No-load Test

There are no specific T parameters to modify when commissioning a drive. Verify
the values and only modify per customer specifications.

P416

Flying Start Mode
0: Disable
1: Set Frequency
2: Stop Frequency Plus 5 Hz
3: Rated Frequency

0

ON

0

3

Setup

P417

Flying Start Motor Speed Search Timeout (s)

50

ON

0

1000

R&D

P438

Flying Start Current Compensation Threshold

100

ON

0

199.99

R&D

P451

Low Speed Voltage Compensation (%)

0.99

OFF

0

10

Setup

P452

Low Speed Voltage Compensation Frequency
Threshold

20

ON

0

100

R&D

P455

Modulation Index

87.99

ON

0

199.99

Setup

Improve the real output of inverter voltage value. For example:
rated voltage of the inverter for 10 kV, if the actual output is
9700V, the need to improve the actual output voltage to 10 kV,
need to change this value

P456

Motor Voltage Upper Limit

87.99

ON

0

199.99

R&D

P457

Flying Start Voltage Recovery Time (s)
(Low Speed Region)

5

ON

0

163.84

R&D

P459

Flying Start Voltage Recovery Time (s)
(High Speed Region)

5

ON

0

163.84

R&D

P460

Rated Output Frequency

50

OFF

0

75

R&D

(1) ON: Can be modified at any time. OFF: Drive must be off to modify.

(2) With Remote DCS only.

Table 12 - Setup and R&D Parameters (Continued)

P
Parameter

Description

Default

Modify
Root

(1)

Min.
Value

Max.
Value

Login
Level

Instruction

T
Parameter

Description

Default

Modify
Root

(1)

Min.
Value

Max.
Value

Login
Level

Instruction

T01

Fault-To-Bypass
0: Disable
1: Enable

0

ON

0

1

Setup

T02

Fault-To-Bypass Delay

3

ON

0

60

Setup

While T1=1 valid

T03

Fault-To-Bypass Delay When Starting
the Motor (0...60s)

60

ON

0

60

Setup

While T1=1 valid

T04

Fault-To-Bypass Minimum Frequency
0...Rated Frequency (Hz)

5

ON

0

Rated
Frequency

Setup

While T1=1 valid

T05

Auto Restart After Input Supply Power Loss
0: Disable
1: Enable

0

ON

0

1

Setup

T06

Input Supply Power Loss Time for
Auto Restart (0...20s)

20

ON

0

20

Setup

T07

Local Frequency Command Selection
0: Digital
1: Analog

0

ON

0

1

Setup

If T7=0, enter the frequency on the HMI. If T7=1, use a
potentiometer to set the frequency on the LV Control
Cabinet. Confirm P262=1.
