Rockwell Automation Publication 6000-IN007A-EN-P - October 2014 21
Preparation and Inspection Chapter 2
Installation Review Prior to commencing the commissioning of the drive, verify the equipment was
properly installed. Identifying errors in the drive installation prior to
commencing the commissioning as opposed to mid-way through the
commissioning process will greatly reduce the amount of time required to
commission the drive. Verify the drive and all associated equipment have the
system power grounding cable installed. Refer to
6000-IN006_-EN-P to review
the contractor’s drive installation responsibilities and understand the scope of the
work you will be reviewing.
Mechanical Installation Inspection
Refer to project-specific EDs to review all electrical connections to external input
and output devices.
Sequence Task Reference Document
1 Verify line up positioning Dimensional Drawings
2 Verify cabinets are bolted together correctly 6000-IN006_-EN-P
3 Verify cabinets are affixed to the floor properly Dimensional Drawings,
6000-IN006_-EN-P
4 Verify fans are installed correctly 6000-IN006_-EN-P
5 Verify power modules are installed correctly 6000-IN006_-EN-P
6 Review duct installation (if applicable) 6000-IN006_-EN-P
7 Verify the cable trenches meet design requirements 6000-IN006_-EN-P
8 Verify required cabinet clearances 6000-IN006_-EN-P
9 Verify there are no scratches or damage to the cabinet body N/A
10 Verify the top cover of the isolation transformer cabinet is securely
mounted 6000-IN006_-EN-P
