Rockwell Automation 1783-BMxxx Stratix 5700 Ethernet Managed Switches User Manual User Manual
Page 73
Rockwell Automation Publication 1783-UM004E-EN-P - June 2014
73
Switch Installation Chapter 2
10. Click Submit.
The switch initializes its configuration for typical industrial EtherNet/IP
applications. The switch then redirects you to the logon page for the
Device Manager Web interface. You can continue to launch the Device
Manager Web interface for further configuration or exit the application.
11. Turn off DC power at the source, disconnect all cables to the switch, and
install the switch in your network.
12. After you complete Express Setup, refresh the computer IP address:
• For a dynamically-assigned IP address, disconnect the computer from
the switch and reconnect the computer to the network. The network
DHCP server assigns a new IP address to the computer.
• For a statically-assigned IP address, change it to the previously
configured IP address.
IMPORTANT
For 1783-BMS4S2SGL or 1783-BMS4S2SGA switches, make sure
DC power is disconnected prior to disconnecting Ethernet cables.
