2 - switch installation, Chapter 2, Switch installation – Rockwell Automation 1783-BMxxx Stratix 5700 Ethernet Managed Switches User Manual User Manual
Page 29: Chapter

Rockwell Automation Publication 1783-UM004E-EN-P - June 2014
29
Chapter
2
Switch Installation
Topic
Page
Stratix 5700 Switch Installation
Install or Remove the SD Card (optional)
Mount the Switch on a DIN Rail
Remove the Switch from the DIN Rail
Wire the Switch DC Power Source
Attach the Switch Power Connectors
Wire the Power over Ethernet DC Power Source
Attach the PoE Power Connector
Install an SFP Module (optional)
Remove SFP Modules from SFP Module Slots
Attach the Alarm Relay Connector to the Switch
Connect to 10/100 and 10/100/1000 Ports
Connect to 10BASE-T, 100BASE-TX, or 1000BASE-T Ports
Connect to a Dual-purpose Port
ArmorStratix 5700 Switch Installation
Install or Remove the SD Card (optional)
Connect the Switch to a DC Power Source
Connect to 10/100 and 10/100/1000 Ports
