Chapter 5 Manage the Switch via the Studio 5000 Environment
• To translate all of the addresses in the public subnet or a portion of the
public subnet, complete the fields as described in the table below.
Field
Description
Type of Entry
Choose Subnet.
Starting Public IP
Address
Type the existing starting address for a device on the public subnet. This address
must correspond to the size of the subnet mask to translate as shown below.
Subnet Mask
Starting Public Subnet Address
255.255.0.0
The last two octets must end in 0.
EXAMPLE: 10.200.0.0
255.255.255.0
The last octet must end in 0.
EXAMPLE: 10.200.1.0
255.255.255.128
The last octet must end in 0 or 128.
EXAMPLE: 10.200.1.0 or 10.200.1.128
255.255.255.192
The last octet must in one of the following: 0, 64, 128, 192.
EXAMPLE: 10.200.1.64
255.255.255.224
The last octet must in one of the following: 0, 32, 64, 96,
128, 160, 192, 224.
EXAMPLE: 10.200.1.32
255.255.255.240
The last octet must in one of the following: 0, 16, 32, 48,
64, 80, 96, 112, 128, 144, 160, 176, 192, 208, 224, 240.
EXAMPLE: 10.200.1.16
Starting Private IP
Address
Type a unique, starting private address to represent the devices. This address must
correspond to the size of the subnet mask to translate as shown below.
Subnet Mask
Starting Private Subnet Address
255.255.0.0
The last two octets must end in 0.
EXAMPLE: 192.168.0.0
255.255.255.0
The last octet must end in 0.
EXAMPLE: 192.168.1.0
255.255.255.128
The last octet must end in 0 or 128.
EXAMPLE: 192.168.1.0 or 192.168.1.128
255.255.255.192
The last octet must in one of the following: 0, 64, 128, 192.
EXAMPLE: 192.168.1.64
255.255.255.224
The last octet must in one of the following: 0, 32, 64, 96,
128, 160, 192, 224.
EXAMPLE: 192.168.1.32
255.255.255.240
The last octet must in one of the following: 0, 16, 32, 48,
64, 80, 96, 112, 128, 144, 160, 176, 192, 208, 224, 240.
EXAMPLE: 192.168.1.16
