214
Rockwell Automation Publication 1783-UM004E-EN-P - June 2014
Chapter 5 Manage the Switch via the Studio 5000 Environment
Table 42 - Time Sync Configuration Tab Fields
Field
Description
Switch PTP Enable
Check to enable the PTP on the device. By default, PTP is enabled on all of the Fast Ethernet and Gigabit Ethernet ports on the switch.
Clear the checkbox to disable the PTP on the device.
The Port Enable and Port State features appear dimmed when the Switch PTP Enable checkbox is cleared.
Port
Displays the port selected for configuration. The port number includes the port type (Fa for Fast Ethernet and Gi for Gigabit Ethernet), and
the specific port number.
EXAMPLE: Gi1/1 is Gigabit Ethernet port 1.
Port Enable
Check to enable the configuration of the port on the device.
Clear the checkbox to disable the port configuration on the device.
The Port Enable feature appears dimmed when the Switch PTP Enable checkbox is cleared.
Port State
Displays the current state of the PTP port on the device.
Valid values:
• Initializing
• Faulty
• Disabled
• Listening
• Pre-Master
• Master
• Uncalibrated
• Slave
The Port State field is blank and dimmed when the Switch PTP Enable checkbox is cleared.
Refresh
Click to refresh the tab with new data from the switch.
Set
Click to send the settings to the switch. The Enter Password dialog box can appear.
Be prepared to enter a valid password to set configuration settings.
The Set button appears dimmed when the switch is offline.
