Appendix A Module-defined Data Types
Module-defined Output Data
Type (8-port switches)
PortFa1_8UnauthorizedDevice
BOOL
Decimal
UnauthorizedDevice:8
AnyPortThreshold
BOOL
Decimal
ThresholdExceeded:0
PortFa1_1Threshold
BOOL
Decimal
ThresholdExceeded:1
PortFa1_2Threshold
BOOL
Decimal
ThresholdExceeded:2
PortFa1_3Threshold
BOOL
Decimal
ThresholdExceeded:3
PortFa1_4Threshold
BOOL
Decimal
ThresholdExceeded:4
PortFa1_5Threshold
BOOL
Decimal
ThresholdExceeded:5
PortFa1_6Threshold
BOOL
Decimal
ThresholdExceeded:6
PortFa1_7Threshold
BOOL
Decimal
ThresholdExceeded:5
PortFa1_8Threshold
BOOL
Decimal
ThresholdExceeded:6
AllPortsUtilization
SINT
Decimal
PortFa1_1Utilization
SINT
Decimal
PortFa1_2Utilization
SINT
Decimal
PortFa1_3Utilization
SINT
Decimal
PortFa1_4Utilization
SINT
Decimal
PortFa1_5Utilization
SINT
Decimal
PortFa1_6Utilization
SINT
Decimal
PortFa1_7Utilization
SINT
Decimal
PortFa1_8Utilization
SINT
Decimal
MajorAlarmRelay
BOOL
Decimal
AlarmRelay:0
MulticastGroupsActive
DINT
Binary
AB:STRATIX_5700_8PORT_MANAGED:I:0
Member Name
Type
Default Display
Style
Valid Values
AB:STRATIX_5700_8PORT_MANAGED:O:0
Member Name
Type
Default Display Style
Valid Values
AllPortsDisabled
BOOL
Decimal
DisablePort:0
PortFa1_1Disable
BOOL
Decimal
DisablePort:1
PortFa1_2Disable
BOOL
Decimal
DisablePort:2
PortFa1_3Disable
BOOL
Decimal
DisablePort:3
PortFa1_4Disable
BOOL
Decimal
DisablePort:4
PortFa1_5Disable
BOOL
Decimal
DisablePort:5
PortFa1_6Disable
BOOL
Decimal
DisablePort:6
PortFa1_7Disable
BOOL
Decimal
DisablePort:7
PortFa1_8Disable
BOOL
Decimal
DisablePort:8
