Rockwell Automation Publication 1783-UM004E-EN-P - June 2014
249
Module-defined Data Types Appendix A
Module-defined Input Data
Type (10-port Gb switches)
AB:STRATIX_5700_10PORT_GB_MANAGED:I:0
Member Name
Type
Default Display Style
Valid Values
Fault
DINT
Binary
AnyPortConnected
BOOL
Decimal
LinkStatus:0
PortFa1_1Connected
BOOL
Decimal
LinkStatus:1
PortFa1_2Connected
BOOL
Decimal
LinkStatus:2
PortFa1_3Connected
BOOL
Decimal
LinkStatus:3
PortFa1_4Connected
BOOL
Decimal
LinkStatus:4
PortFa1_5Connected
BOOL
Decimal
LinkStatus:5
PortFa1_6Connected
BOOL
Decimal
LinkStatus:6
PortFa1_7Connected
BOOL
Decimal
LinkStatus:7
PortFa1_8Connected
BOOL
Decimal
LinkStatus:8
PortGi1_1Connected
BOOL
Decimal
LinkStatus:9
PortGi1_2Connected
BOOL
Decimal
LinkStatus:10
AnyPortUnauthorizedDevice
BOOL
Decimal
UnauthorizedDevice:0
PortFa1_1UnauthorizedDevice
BOOL
Decimal
UnauthorizedDevice:1
PortFa1_2UnauthorizedDevice
BOOL
Decimal
UnauthorizedDevice:2
PortFa1_3UnauthorizedDevice
BOOL
Decimal
UnauthorizedDevice:3
PortFa1_4UnauthorizedDevice
BOOL
Decimal
UnauthorizedDevice:4
PortFa1_5UnauthorizedDevice
BOOL
Decimal
UnauthorizedDevice:5
PortFa1_6UnauthorizedDevice
BOOL
Decimal
UnauthorizedDevice:6
PortFa1_7UnauthorizedDevice
BOOL
Decimal
UnauthorizedDevice:7
PortFa1_8UnauthorizedDevice
BOOL
Decimal
UnauthorizedDevice:8
PortGi1_1UnauthorizedDevice
BOOL
Decimal
UnauthorizedDevice:9
PortGi1_2UnauthorizedDevice
BOOL
Decimal
UnauthorizedDevice:10
AnyPortThreshold
BOOL
Decimal
ThresholdExceeded:0
PortFa1_1Threshold
BOOL
Decimal
ThresholdExceeded:1
PortFa1_2Threshold
BOOL
Decimal
ThresholdExceeded:2
PortFa1_3Threshold
BOOL
Decimal
ThresholdExceeded:3
PortFa1_4Threshold
BOOL
Decimal
ThresholdExceeded:4
PortFa1_5Threshold
BOOL
Decimal
ThresholdExceeded:5
PortFa1_6Threshold
BOOL
Decimal
ThresholdExceeded:6
PortFa1_7Threshold
BOOL
Decimal
ThresholdExceeded:7
PortFa1_8Threshold
BOOL
Decimal
ThresholdExceeded:8
PortGi1_1Threshold
BOOL
Decimal
ThresholdExceeded:9
PortGi1_2Threshold
BOOL
Decimal
ThresholdExceeded:10
AllPortsUtilization
SINT
Decimal
PortFa1_1Utilization
SINT
Decimal
PortFa1_2Utilization
SINT
Decimal
PortFa1_3Utilization
SINT
Decimal
PortFa1_4Utilization
SINT
Decimal
