About the Switches Chapter 1
Studio 5000 Environment
You can manage the switch by using the Logix Designer application in the
Studio 5000 environment. The Logix Designer application is IEC 61131-3
compliant and offers relay ladder, structured text, function block diagram, and
sequential function chart editors for you to develop application programs.
Hardware Requirements
Cisco Network Assistant
Cisco Network Assistant is a Web interface that you download from Cisco’s
website and run on your computer. It offers advanced options for configuring and
monitoring multiple devices, including switches, switch clusters, switch stacks,
routers, and access points.
To use the software, follow these steps.
.
You must be a registered user, but you need no other access privileges.
2. Find the Network Assistant installer.
3. Download the Network Assistant installer, and run it.
You can run it directly from the Web if your browser offers this choice.
4. When you run the installer, follow the displayed instructions.
5. In the final panel, click Finish to complete the Network Assistant
installation.
6. See the Network Assistant online help for more information.
Attribute
Requirement
Processor speed
Pentium II 450 MHz min
Pentium III 733 MHz (or better) recommended
RAM
128 MB min
256 MB recommended
Free hard drive space
3 GB
Optical drives
DVD
Video requirements
256-color VGA graphics adapter
800 x 600 min resolution (True Color 1024 x 768 recommended)
Resolution
800 x 600 min resolution (True Color 1024 x 768 recommended)
