B-1 Publication 900-UM007D-EN-E - January 2011
Appendix
B
Parameter Operations List Function Groups
Global Temperature input:Controllers with Thermocouple/Resistance
Thermometer (RTD) and Millivolt (0…50) Inputs
Analog input:Controllers with Analog (e.g., 4…20 mA, 1…5V DC, etc.) Inputs
Table B.A — Operation Function Group
Parameters Characters Setting (Monitor) Value Display Default Unit
Set
Value
Process Value Temperature: According to indication
range for each sensor. Analog:
Scaling lower limit
-5% FS to Scaling upper limit+5% FS EU
Set Point SP Lower-Limit to SP Upper-Limit 0 EU
Auto/Manual Switch a-m
Multi-SP Set Point Setting
m-sp
0…3 0 None
Set Point During SP Ramp sp-m SP Lower-Limit to SP Upper-Limit EU
Heater Current 1 Value Monitor
ct1
0.0…55.0 A
Heater Current 2 Value Monitor ct2 0.0…55.0 A
Leakage Current 1 Monitor
lcr1
0.0…55.0 A
Leakage Current 2 Monitor lcr2 0.0…55.0 A
Program Start
prst
RSET, STRT
rset
strt
RSET None
Soak Time Remain
sktr
0…9999 min or h
RUN/STOP
r-s
RUN/STOP
run
stop
RUN None
Alarm Value 1
al-1 −1999…9999
0 EU
Alarm Value Upper-Limit 1 al1h −1999…9999 0 EU
Alarm Value Lower-Limit 1
al1l −1999…9999
0 EU
Alarm Value 2 al-2 −1999…9999 0 EU
Alarm Value Upper-Limit 2
al2h −1999…9999
0 EU
Alarm Value Lower-Limit 2 al2l −1999…9999 0 EU
Alarm Value 3
al-3 −1999…9999
0 EU
Alarm Value Upper-Limit 3 al3h −1999…9999 0 EU
Alarm Value Lower-Limit 3
al3l −1999…9999
0 EU
MV Monitor (heating) o −5.0…105.5 (standard)
0.0…105.0 (heating/cooling) %
MV Monitor (cooling)
c-o
0.0…105.0 %
